BYO Toulouse
Article 1008
Benefits of BYO the BYO Toulouse:
- Modular system allowing devices to be easily adaptable.
- Colour themes available: Happy, Crazy, Sweet and Nature.
- Available in any standard RAL colour.
- Ropes are available in the colours: reed, blue, green and black.
- TÜV certified.
Product description
The BYO Toulouse has several climbing platforms with coloured side panels where children can meet. In addition, the BYO Toulouse has the play elements: slide, ladder, climbing net, sliding pole and a viewing window in a side panel. The BYO Toulouse is standard equipped with yellow/red panels and a red panel with viewing window. The climbing net comes standard in the color red.
Play values of the BYO Toulouse:
- Meeting & Fantasy
- Peekaboo
- Slide
- Climbing, ladder
- Sliding pole
Download PDF
1008-R05-INS.pdf 957 KB
1008-R05-INS.dwg 3 MB
Maak account aan om meer bestanden te zien
Dimensions
(LxWxH)
4,51 x 2,71 x 2 m
Age
min-max
5 - 10 years
Fall height
1 m
| Tags | Blog Glijden Klettern Klimmen Sliding |
|---|---|
| Article | 1008 |
| Description | BYO Toulouse |
| Age category as of | 5 |
| Age category up to | 10 |
| Length of equipment | 4,51 m |
| Width of equipment | 2,71 m |
| Height of equipment | 2,00 m |
| Safezone length | 7,90 m |
| Safezone width | 5,70 m |
| Fall height | 1 m |
| Foundation m2 (min. calculation) | 50,18 m² |
| Total weight | 409 kg |
| Heaviest part | 63 kg |
| Number of people | 10 |
| Assembly hours (couple) | 18 |
| Materials (inc. percentage) | RVS (98) Polyester (2) |
| Construction materials | RVS (buis 88,9x3mm en vloer 2,5mm), Polyester touw met stalen kern Ø16 mm, bevestigingsmaterialen: Torx M8x16 en stelschroef M8x10 |
